www.scheppach.com / service@scheppach.com / +(49)-08223-4002-99 / +(49)-08223-4002-58
18
|
GB
Sound power level L
wA
96 dB(A)
Sound pressure level L
pA
73,4 dB(A)
Uncertainty K
wA/pA
1,96 dB(A)
7. Before starting the equipment
• Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
• Check the equipment for damage which may have
occurred in transit. Report any damage immedi-
ately to the transport company which was used to
deliver the compressor.
• Install the compressor near the point of consump-
tion.
• Avoid long air lines and supply lines (extension ca-
bles).
• Make sure that the intake air is dry and dustfree.
• Do not install the compressor in a damp or wet
room.
• The compressor may only be used in suitable rooms
(with good ventilation and an ambient temperature
from +5 °C to 40 °C). There must be no dust, acids,
vapors, explosive gases or inammable gases in the
room.
• The compressor is designed to be used in dry
rooms. It is prohibited to use the compressor in ar-
eas where work is conducted with sprayed water.
• The compressor may only be used outdoor briey
when the ambient conditions are dry.
• The compressor must always be kept dry and must
not be left outdoors after work is complete.
8. Attachment and operation
n IMPORTANT!
You must fully assemble the appliance before us-
ing it for the rst time!
You will require the following tools for assembly and in-
stallation:
• 2 x open-ended wrench size 17 mm (not included)
8.1 Fitting the wheels (10)
Fit the supplied wheels (10) as shown in Figure 5.
8.2 Fitting the supporting foot (7)
Fit the supplied supporting foot (A) as shown in Fig. 6.
8.3 Mains connection
• The compressor is equipped with a mains cable
with shock-proof plug. This can be connected to
any 230-240 V~ 50 Hz shock-proof socket which is
protected by a 16 A fuse.
• Before you use the machine, make sure that the
mains voltage is the same as the operating voltage
(see the rating plate).
Operating pressure vessels
• You must keep your pressure vessel in good work-
ing order, operate the vessel correctly, monitor the
vessel, carry out necessary maintenance and re-
pair work immediately and meet the relevant safety
precautions.
• The supervisory authority may enforce essential
control measures in individual cases.
• A pressure vessel is not allowed to be used if it has
faults or deciencies that can endanger workers or
third parties.
• Check the pressure vessel for signs of rust and
damage each time before using. Do not use the
compressor with a damaged or rusty pressure ves-
sel. If you discover any damage, then please con-
tact the customer service workshop.
Do not lose these safety instructions
m WARNING! This electric tool generates an elec-
tromagnetic eld during operation. This eld can im-
pair active or passive medical implants under certain
conditions. In order to prevent the risk of serious or
deadly injuries, we recommend that persons with
medical implants consult with their physician and the
manufacturer of the medical implant prior to operat-
ing the electric tool.
6. Technical data
Mains connection 230 V~ 50 Hz
Motor rating 110 0 W
Operating mode S1
Compressor speed 2850 min
-1
Pressure vessel capacity approx. 24 l
Operating pressure approx. 8 bar
Theoretical intake
capacity
approx. 165 l/min
Theoretical delivery rate approx. 95 l/min
Protection type IP 20
Weight of the unit in kg 19,2 kg
Subject to technical changes!
The noise emission values were measured in accord-
ance with EN ISO 3744.
Wear hearing protection.
The eects of noise can cause a loss of hearing.
m Warning: Noise can have serious eects on your
health. If the machine noise exceeds 85 dB (A),
please wear suitable hearing protection.
