9. Foot
10. Door lock
11. Housing doors
11a. Safety switch
12. On/off switch
13. Adjustment handle (top band wheel)
13a. Wing nut (top band wheel)
14. Main frame
15. Graduated scale (pivot range)
16. Suction port
17. Band saw blade
18. Wing screw (band saw blade guide)
18a. Adjusting nut (band saw blade guide)
19. Transverse cutting gauge
19a. Knurled nut
20. Parallel stop
20a. Clamping bar
21. Push stick
22. Wing nut
23. Locking handle
24. Clamping plate
25. Top support bearing
25a. Allen screw
26. Top guide pins
26a. Allen screws
27. Top retainer
27a. Allen screw (2x)
28. Bottom support bearing
28a. Allen screw
29. Bottom retainer
29a. Allen screw
30. Bottom guide pins
30a. Allen screws
31. End stop screw (saw table adjustment)
31a. Counternut (saw table adjustment)
32. Push rod retainer
3 Scope of delivery (Fig. 1-3)
Item Quantity Designation
7. 1 x Saw table
17. 1 x Band saw blade (pre-assembled)
20. 1 x Parallel stop
21. 1 x Push stick
A. 1 x Slotted-head screwdriver
B. 1 x Open-ended spanner, size 10/13
C. 1 x Allen key, 3 mm
D. 1 x Allen key, 4 mm
E. 1 x Allen key, 5 mm
1 x Band saw
1 x Operating manual
4 Proper use
The band saw is used for the longitudinal and transverse
cutting of timbers or wood-like workpieces. Round materi-
als may only be cut using suitable holding devices.
WARNING
Do not use the product to cut materials other than those
described in the operating manual.
WARNING
The supplied band saw blade is only intended for the
sawing of wood! Do not use this blade for sawing fire-
wood!
The product may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or injuries
of any type resulting from this.
Only suitable band saw blades may be used for the prod-
uct.
An element of the intended use is also the observance of
the safety instructions, as well as the assembly instruc-
tions and operating information in the operating manual.
Persons who operate and maintain the product must be
familiar with the manual and must be informed about po-
tential dangers.
The liability of the manufacturer and resulting damages
are excluded in the event of modifications of the product.
Please note that our products were not designed with the
intention of use for commercial or industrial purposes. We
assume no guarantee if the product is used in commercial
or industrial applications, or for equivalent work.
Explanation of the signal words in
the operating manual
DANGER
Signal word to indicate an imminently haz-
ardous situation which, if not avoided, will re-
sult in death or serious injury.
WARNING
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in death or serious injury.
CAUTION
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in minor or moderate injury.
ATTENTION
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in product or property damage.
5 Safety instructions
General power tool safety warnings
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
WARNING
Read all safety warnings, instructions, illus-
trations and specifications provided with this
power tool.
Failure to follow all instructions listed below may result
in electric shock, fire and/or serious injury.
24 | GB www.scheppach.com
