www.scheppach.com
20
|
GB
Lubricants are used inside the garden pump which may
contaminate the liquids owing out if the product is op-
erated improperly or damaged.
Warning! This power tool generates an electromag-
netic eld during operation. This eld can impair active
or passive medical implants under certain conditions.
In order to prevent the risk of serious or deadly injuries,
we recommend that persons with medical implants
consult with their physician and the manufacturer of
the medical implant prior to operating the power tool.
Residual risks
The machine has been built according to the state-of-
the-art and the recognised technical safety require-
ments. However, individual residual risks can arise
during operation.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Before performing setting or maintenance work, un-
plug the mains plug.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the “Safety infor-
mation” and the “Proper use” together with the oper-
ating manual as a whole are observed.
6. Technical data
AC motor 230V~ / 50 Hz
Nominal power 1100 W
Max. delivery ow 4600 l/h
Max. delivery height 45 m
Max. delivery pressure 4.5 bar
Max. suction height 7 m
Pressure and suction connection G1”
Max. water temperature 35°C
Protection class I
Protection category IPX4
Weight 8.1 kg
*Technical changes reserved!
• Please read the information on “Cleaning, mainte-
nance, storage” in the operating manual. All addi-
tional measures, in particular opening the product,
must be carried out by a qualied electrician. In the
event of repair, always contact our service centre.
Electrical safety instructions
• When operating the product, the power plug must
be freely accessible after installation.
• Before you put your new garden pump into opera-
tion, have it professionally tested:
- Earthing, connection of the neutral line and resid-
ual current circuit breaker must comply with the
safety regulations of the power supply companies
and function properly,
- Protect the electrical plug connections from mois-
ture.
- If there is a risk of ooding, t the plug connec-
tions in the ood-proof area.
• Ensure that the mains voltage corresponds to the
specications on the type plate.
• Carry out the electrical installation in accordance
with the national regulations.
• Only connect the product to a socket with a residual
current circuit breaker (FI switch) with a rated resid-
ual triggering current of up to 30 mA; Fuse at least
6 amps.
• Before each use, always check the product, cable
and plug for damages. Defective cables must not be
repaired but replaced with a new ones.
Have product damages repaired by a specialist.
• If the connection cable for the product is damaged
then it must be replaced by the manufacturer or
their customer services personnel or by a similarly
qualied person, in order to avoid hazards.
• Do not use the cable to pull the plug out of the out-
let.
• Protect the cable from heat, oil and sharp edges.
• Do not carry or attach the product by the cable.
• Use only extension cables that are splash-proof
and intended for outdoor use. Always unroll a ca-
ble drum completely before use. Check the cable for
damage.
• Pull out the mains plug before all work on the prod-
uct, in work breaks and when not in use.
• Mains connection cables shall not have a smaller
cross-section than rubber hose lines with the desig-
nation H07RN-F 3*1.0mm². The cable length must
be 10 m. The conductor core cross-section of the
extension cable must be at least 1.5 mm
2
.
