Je bekijkt pagina 21 van 72
www.scheppach.com
GB
|
21
Delivery rate max. 9000 l/h
Delivery height max. 6 m
Max. submersion depth 7 m
Hose connection
G1 ½” = 47,8 mm
38 mm
G1” = 33.2 mm
25 mm
Water temperature max. 35°C
Protection category IPX8
Protection class I
Max. particle size 30 mm
Weight 3.6 kg
Subject to technical changes!
7. Unpacking
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of the
warranty period. Familiarise yourself with the prod-
uct by means of the operating manual before using
for the rst time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
m ATTENTION!
The product and the packaging material are not
children's toys! Do not let children play with plas-
tic bags, lms or small parts! There is a danger of
choking or suocating!
8. Assembly / Before commissioning
Connecting the hose (Fig. 2)
The pump is installed either with a xed pipeline or
with a exible hose line.
1. Screw the pump connection bend (4) onto the
pressure connection of the pump (5).
• If there is a risk of ooding, t the plug connections
in the ood-proof area.
• Ensure that the mains voltage corresponds to the
specications on the type plate.
• Carry out the electrical installation in accordance
with national regulations.
• Only connect the device to a mains socket with a re-
sidual current device (RCD) with a rated leakage cur-
rent of no more than 30 mA; fuse at least 6 amps.
• Before each use, check the device, cables and con-
nectors for damage. Defective cables must not be
repaired but replaced with a new ones. Have dam-
age to your device repaired by a specialist.
• If the connection cable of this unit is damaged, it
must be replaced by the manufacturer or their ser-
vice department or a similar qualied person in or-
der to avoid hazards.
• Do not use the cable to pull the plug out of the outlet.
• Protect the cable from heat, oil and sharp edges.
• Do not carry or fasten the device by the cable.
• Use only extension cables that are splash-proof and
intended for outdoor use. Always unroll a cable drum
completely before use. Check the cable for damage.
• Disconnect the mains plug from the socket before
carrying out any work on the device, as well as dur-
ing breaks in work and when not in use.
• Mains connection cables shall not have a smaller
cross-section than rubber hose lines with the desig-
nation H05 RN8-F. The cable length must be 10 m.
The conductor core cross-section of the extension
cable must be at least 1.5 mm
2
.
Lubricants are used inside the pump which may con-
taminate the liquids owing out of the device if the de-
vice is operated improperly or damaged.
Warning! This power tool generates an electromagnet-
ic eld during operation. This eld can impair active or
passive medical implants under certain circumstances.
In order to prevent the risk of serious or deadly injuries,
we recommend that persons with medical implants
consult with their physician and the manufacturer of
the medical implant prior to operating the power tool.
6. Technical data
Product L x W x H 300 x 150 x 420 mm
Mains power connection 230 V ~ 50 Hz
Rated input 400 W
