www.scheppach.com
24
|
GB
Installing the lter (33) (Fig. 5, 6)
Never use the device without lter! Always ensure that
the lters are correctly tted.
Installing the foam lter (33)
1. For wet vacuuming, open and remove the lter
cage (3a) by turning it anti-clockwise (Fig. 6).
2. Pull o the clipped cover cap (3b) with a screw-
driver (not included in the scope of delivery), pull
the foam lter (33) over the lter cage with safety
oat valve (3c) and ret the cover cap (3b) (Fig. 5).
3. Now reinsert the lter cage by turning it clockwise
(Fig. 6).
To avoid tearing the foam lter (33),
• only insert a dry lter
• knock the edge of the lter over a little to insert it and
then roll it back again.
Fit the folded lter (31) and foam lter (32) (not in-
cluded in the scope of delivery)
1. Open and remove the lter cage (3a) by turning it
anti-clockwise (Fig. 6).
2. Insert the HEPA lter (31) or foam lter (32) and re-
place the lter cage by turning it clockwise (Fig. 6).
Installing the paper lter bag (34) (g. 7)
It is recommended to use an additional paper lter bag
(34) when vacuuming ne, dry dirt.
1. Slide the paper lter bag (34) over the suction
opening in the stainless steel container (1).
The paper lter bag (34) is only suitable for dry
vacuuming. The paper lter bag (34) makes it eas-
ier to dispose of the dust collected.
Filling the water tank (Fig. 15)
The water tank (9) can be removed for lling or lled
directly at the device.
1. Fill the water tank (9) through the opening (17) with
clear water (max. 3 l). Pay attention to the mark-
ings on the container (10).
2. If the water tank is heavily contaminated or
stained, add a little cleaning agent, e.g. carpet and
upholstery cleaner.
Installing the water tank (Fig. 4)
1. Take the water tank (9) by the handle (18) and
place it in the openings of the caster mounting
base (13).
2. Now press the water tank (9) against the detent
(1a) until it locks into place.
• Familiarise yourself with the device by means of the
operating manual before using for the rst time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for your equip-
ment.
m WARNING!
The device and the packaging material are not
children's toys! Do not let children play with plas-
tic bags, lms or small parts! There is a danger of
choking or suocating!
9. Assembly / Before commissioning
m ATTENTION!
Prior to use, ensure that the device has been correct-
ly and fully assembled.
Unpacking (Fig. 1, 2)
• Release the locking hooks (8) and remove the ma-
chine head with lter cage (3). The accessories are lo-
cated inside the stainless steel container (1). Only the
extension pipes (25) are located outside the stainless
steel container (1) in the packaging. Remove all of the
accessories from the stainless steel container (1).
Installation of the roller mounts (11 + 12) (Fig. 3)
1. Turn the stainless steel container (1) upside down.
(The machine head with lter cage (3) must be re-
moved.)
2. Slide the wheels (11) into the recesses provided on
the caster mounting base (13) and screw them in
place with the screws (30).
Installation of the castors (12) (Fig. 3)
1. Press the two deection rollers (12) into the holes
provided in the roller mounts (12a).
Installing the machine head with lter cage (3) (Fig. 8)
1. Place the machine head with lter cage (3) on the
stainless steel container (1).
2. Secure the machine head (3) with the locking hooks
(8). When installing the machine head with lter
cage (3), ensure that the locking hooks (8) latch into
place correctly. The water channel connection (4)
must be above the vacuum connection (2).
