Keep the operating manual in a good place and hand
over all documents when passing the product on to third
parties.
2 Product description (Fig. 1-4)
1. Chuck opening
2. Quick-release chuck
3. Torque adjusting ring
4. Gear selector switch
5. Battery charge level
6. Rotational direction switch
7. Battery
8. Release button (battery)
9. Battery mount
10. On/off switch
11. LED work lamp
12. Battery charger
13. Battery charger/battery mount
14. LED ( battery charger)
15. Wall bracket
16. Bits
17. Bit holder
18. Metal drill
19. Wood drill
20. Cutter knife
21. Mine
22. Carpenter's pencil
23. Sockets
24. Tape measure (3m)
25. Center punch
3 Scope of delivery (Fig. 1, 2)
Item Quantity Designation
7. 2 x Battery 12 V 1.3 Ah
(item no. 5909324001)
12. 1 x Battery charger 12V 2.4 A
(item no. 5909324003)
16. 40 x Bits
17. 1 x Bit holder
18. 14 x Metal drill
19. 5 x Wood drill
20. 1 x Cutter knife
21. 1 x Mine
22. 1 x Carpenter's pencil
23. 9 x Sockets
24. 1 x Tape measure (3m)
25. 1 x Center punch
1 x Cordless drill
1 x Operating manual
4 Proper use
The product is intended for screwing in and unscrewing
screws, as well as for drilling into wood, metal and plastic.
The product may only be used in the intended manner.
Any use beyond this is improper. The user, not the manu-
facturer, is responsible for damages or injuries of any type
resulting from this.
An element of the intended use is also the observance of
the safety instructions, as well as the assembly instruc-
tions and operating information in the operating manual.
Persons who operate and maintain the product must be
familiar with the manual and must be informed about po-
tential dangers.
The liability of the manufacturer and resulting damages
are excluded in the event of modifications of the product.
The product may only be operated with original parts and
original accessories from the manufacturer.
The safety, operating and maintenance specifications of
the manufacturer, as well as the dimensions specified in
the technical data, must be observed.
Please note that our products were not designed with the
intention of use for commercial or industrial purposes. We
assume no guarantee if the product is used in commercial
or industrial applications, or for equivalent work.
Explanation of the signal words in
the operating manual
DANGER
Signal word to indicate an imminently haz-
ardous situation which, if not avoided, will re-
sult in death or serious injury.
WARNING
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in death or serious injury.
CAUTION
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in minor or moderate injury.
ATTENTION
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in product or property damage.
5 Safety instructions
WARNING
Read all safety warnings, instructions, illus-
trations and specifications provided with this
power tool.
Failure to follow all instructions listed below may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1) Work area safety
a) Keep your work area clean and well-lit. Cluttered or
dark areas invite accidents.
b) Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable liq-
uids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
18 | GB www.scheppach.com
