WARNING
This power tool generates an electromagnetic field
during operation. This field can impair active or passive
medical implants under certain circumstances. In order
to prevent the risk of serious or deadly injuries, we rec-
ommend that persons with medical implants consult
with their physician and the manufacturer of the medical
implant prior to operating the power tool.
WARNING
In case of extended working periods, the operating per-
sonnel may suffer circulatory disturbances in their
hands (vibration white finger) due to vibrations.
Raynaud's syndrome is a vascular disease that causes
the small blood vessels on the fingers and toes to
cramp in spasms. The affected areas are no longer
supplied with sufficient blood and therefore appear ex-
tremely pale. The frequent use of vibrating products can
cause nerve damage in people whose circulation is im-
paired (e.g. smokers, diabetics).
If you notice unusual adverse effects, stop working im-
mediately and seek medical advice.
ATTENTION
The product is part of the 20V IXES series and may on-
ly be operated with batteries of this series. Batteries
may only be charged with battery chargers of this se-
ries. Observe the manufacturer's instructions.
WARNING
Follow the safety and charging instructions
and correct usage given in the instruction
manual of your 20V IXES Series battery and
charger. A detailed description of the
charging process and further information are
provided in this separate manual.
6 Technical data
Rated voltage 20 V
Idle speeds n
0
• Gear 1
• Gear 2
0 - 400 rpm
0 - 1550 rpm
Stroke rates
• Gear 1
• Gear 2
0 – 6000 rpm
0 – 22500 rpm
Max. torque 50 Nm
Chuck span Ø 1.5 - 13 mm
Weight (without battery) 1.34 kg
Drilling diameter for
wood
max. 30 mm
Drilling diameter for steel max. 13 mm
Battery charger SBC2.4
Input
Rated voltage 230 – 240 V~50 Hz
Rated power
consumption
65 W
Fuse (internal) 3.15 A
Output
Rated voltage 21.5 V
Rated current 2.4 A
Protection class II (Double insulation)
Loading time:
2 Ah approx. 60 min
4 Ah approx. 120 min
Battery (Li-Ion) SBP2.0
Number of battery cells 5
Rated voltage max. 20 V
Capacity 2.0 Ah
Power 40 Wh
Max. temperature. 50°C
Charging process
temperature
4 °C – 40 °C
Operation temperature -20 °C – 50 °C
Storage temperature 0 °C – 45 °C
Subject to technical changes!
Noise and vibration
WARNING
Noise can have serious effects on your health. If the
machine noise exceeds 85 dB, please wear suitable
hearing protection for you and persons in the vicinity.
The noise and vibration values have been determined in
accordance with EN 62841-1.
Noise data
Sound pressure L
pA
84.3 dB
Measurement uncertainty K
pA
5 dB
Sound power L
wA
92.3 dB
Measurement uncertainty K
wA
5 dB
Vibration parameters (hand/arm vibration)
Hammer-drilling
Vibration a
h
8.417 m/s
2
Measurement uncertainty K 1.5 m/s
2
Drilling
Vibration a
h
4.170 m/s
2
Measurement uncertainty K 1.5 m/s
2
The total vibration emission values specified and the de-
vice emissions values specified have been measured in
accordance with a standardised test procedure and can
be used for comparison of one electric tool with another.
The total noise emission values specified and the total vi-
bration emission values specified can also be used for an
initial estimation of the load.
GB | 21www.scheppach.com
