• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
8 Before commissioning
WARNING
Danger of injury!
Remove the battery from the power tool before carrying
out any work on the power tool (e.g. maintenance, tool
change, etc.) and when transporting and storing it.
There is a risk of injury if the on/off switch is operated
unintentionally.
8.1 Assembling/removing the
additional handle (3) (Fig. 1)
ATTENTION
Only use the product with the additional handle fitted.
Assembling the additional handle
Note:
The additional handle can be screwed in on the left, right
or top of the product head.
1. Tighten the additional handle (3) clockwise.
Removing the additional handle
1. Remove the additional handle (3) from the product by
unscrewing it anticlockwise.
8.2 Inserting/removing the battery (17)
in the battery mount (18) (Fig. 1, 7)
Inserting the battery
1. Push the battery (17) into the battery mount (18). The
battery (17) clicks into place audibly.
Removing the battery
1. Press the unlock button (16) of the battery (17) and
remove it from the battery mount (18).
8.3 Mounting the protective cover (15)
for cutting (Fig. 6)
ATTENTION
When cutting with bonded abrasives, always use the
protective cover for cutting.
1. Switch the product off and remove the battery as de-
scribed in 8.2.
2. Push the protective cover (15) onto the cover (4) until
it engages.
3. When removing, the protective cover (15) must be
pulled forward slightly in order to release it.
8.4 Adjusting the protective cover (4)
(Fig. 2,5)
WARNING
Always use the angle grinder with the protective cover.
The protective cover must be attached securely to the
angle grinder. Adjust it so that the highest degree of
safety is achieved, i.e. the smallest possible part of the
grinding wheel is revealed to the operator. The protec-
tive cover is intended to protect the operator from frag-
ments and accidental contact with the grinding wheel.
WARNING
Make sure that the protective cover is mounted at least
at the same angle as the additional handle. Otherwise,
you can be injured on the roughing and cutting wheel.
1. Rotate the protective cover (4) into the required posi-
tion (working position). Make sure that the protective
cover (4) is positioned so that the protective cover fix-
ing (12) sits above one of the 5 cambers (13) of the
protective cover (4) (Fig. 5).
ATTENTION
Make sure that the protective cover fixing sits firmly in
the respective camber.
8.5 Mounting/changing the roughing/
cutting wheel
ATTENTION
Always wear protective gloves when changing the
roughing/cutting wheel.
– Observe the dimensions of the roughing or cutting
wheels.
– The diameter of the hole must fit the receptacle
flange without play.
– Do not use reduction pieces or adapters.
Note:
Always use dirt-free discs.
WARNING
Danger of injury!
Only press the spindle locking button when the recepta-
cle spindle is stationary.
1. Push the spindle locking button (5) to block the gear.
2. Undo the clamping nut (6) using the two-hole assem-
bly key (9).
3. Place the roughing or cutting wheel onto the recepta-
cle flange (7) with the labelled side facing the product.
4. Then place the clamping nut (6) back onto the recep-
tacle spindle (8) with the raised side facing upwards.
GB | 23www.scheppach.com
