Je bekijkt pagina 31 van 328
GB
|
31
12. Oil dipstick
13. Drive wheel
14. Wheel height adjustor lever
15. Discharge ap
16. Catch basket
17. Pull cable starter, 17a. Electric starter
18. Electric starter unit
19. Mulching insert
20. Battery
21. Battery charger
3. Scope of delivery
Fig. 1 (a - j)
a) 2 x Round-headed screws M8
b) 2 x Washer, small
c) 2 x washer, large
d) 4 x Plastic nut
e) 1 x Cable clip
f) 4 x Screws
g) 4 x Velcro tape
h) 1 x Operating manual
i) 2 x Plastic washer
j) 2 x Plastic holder
• Mulching insert (19)
• Side discharge (8)
• Battery (20)
• Battery charger (21)
4. Proper use
The petrol lawnmower is intended for private use i.e.
for use in home and gardening environments. Private
use of the lawnmower refers an annual operating
time generally not exceeding that of 50 hours, during
which time the machine is primarily used to maintain
small-scale, residential lawns and home/hobby gar-
dens. Public facilities, sporting halls, and agricultural/
forestry applications are excluded.
The product may only be used in the intended man-
ner. Any use beyond this is improper.
The user/operator, not the manufacturer, is responsible
for damages or injuries of any type resulting from this.
An element of the intended use is also the obser-
vance of the safety instructions, as well as the as-
sembly instructions and operating information in the
operating manual.
Persons who operate and maintain the product must
be familiar with the manual and must be informed
about potential dangers.
The liability of the manufacturer and resulting dam-
ages are excluded in the event of modications of the
product.
The product may only be operated with original parts
and original accessories from the manufacturer.
The safety, operating and maintenance specications
of the manufacturer, as well as the dimensions speci-
ed in the technical data, must be observed.
1. Introduction
Manufacturer:
Woodster GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer
We hope your new device brings you much enjoy-
ment and success.
Note:
In accordance with the applicable product liability
laws, the manufacturer of this device assumes no lia-
bility for damage to the device or caused by the device
arising from:
• Improper handling
• Failure to comply with the operating instructions.
• Repairs carried out by third parties, unauthorised
specialists
• Installing and replacing non-original spare parts
• Improper use
• Failure of the electrical system in the event of the
electrical regulations and VDE provisions 0100,
DIN 57113 / VDE 0113 not being observed
Note:
The operating manual is part of this product. It in-
cludes important instructions for the safe, proper
and economic operation of the product, for avoiding
danger, for minimising repair costs and downtimes
and for increasing the reliability and extending the
service life of the product. In addition to the safety
instructions in this operating manual, you must also
observe the regulations applicable to the operation of
the product in your country.
Familiarise yourself with all operating and safety in-
structions before using the product. Only operate the
product as described and for the specied areas of
application. Keep the operating manual in a good
place and hand over all documents when passing the
product on to third parties.
2. Device description
Fig. 1 (1 - 21)
1. Handle
2. Drive lever
3. Engine brake lever
4. Upper push bar; 4a. Lower push bar
5. Quick clamp lever
6. Fuel tank
7. Air lter
8. Side discharge (side discharge ap and side dis-
charge adapter)
9. Idler
10. Spark plug
11. Exhaust pipe
