www.scheppach.com
34
|
GB
m Caution: Regularly remove all lawn and weed de-
bris to prevent the shaft tube from overheating. Lawn/
grass/weed debris gets caught underneath the shield,
this prevents sucient cooling of the shaft tube. Care-
fully remove the residues with a screwdriver or similar.
(g. 42)
Dierent cutting techniques
If the device is assembled correctly, it cuts weeds and
tall grass in hard-to-reach places, such as along fenc-
es, walls and foundations, and around trees. It can al-
so be used for “mowing” to remove wild growth close
to the ground for preparing a garden or for cleaning out
a specic area. (g. 43)
m Attention: Even with careful use, cutting on foun-
dations, stone or concrete walls, etc. will result in
above-normal wear of the thread.
Trimming/mowing
Swing the trimmer from side to side in a sickle-like mo-
tion. Always keep the thread coil parallel to the ground.
Check the terrain and set the desired cutting height.
Guide and hold the thread coil at the desired height to
get an even cut. (g. 43)
Low trimming
Hold the trimmer with a slight inclination right in front
of you so that the bottom of the thread coil is above
the ground and the thread hits the correct intersection.
Always cut away from yourself. Do not pull the trimmer
towards you.
Cutting on fence/foundation
When cutting, slowly approach wire mesh fences, pick-
et fences, natural stone walls and foundations to cut
close to them, but without hitting the obstacle with the
thread. If the thread comes into contact with stones,
stone walls or foundations, for example, it wears out
or frays. If the thread hits the fence mesh, it breaks o.
Trimming around trees
Trim around tree trunks, approaching slowly so that the
thread does not touch the bark. Walk around the tree, cut-
ting from left to right. Approach grass or weeds with the
tip of the thread and tilt the thread coil slightly forward.
Warning: Be extremely careful when mowing it. Main-
tain a spacing of 30 metres between yourself and other
persons or animals for any such tasks.
9. Adjust the thread length when working:
This device has a cutting head that works on the
“tap and go” principle.
You can release more thread by tapping the pulley
with the cutting head while the engine is running
at maximum speed:
The nylon thread is automatically released and the
cutting edge cuts o the protruding length. (g. 41)
10. If problems occur, switch o the engine; the de-
vice stops. If you want to stop the cutting head,
release the throttle (8). (g. 27)
11. If a problem occurs, pull the pin of the safety belt
and release the trimmer immediately. Switch o
the engine (g. 22)
12. When the engine is warm, the throttle can be set
directly to the on position when the machine is re-
started.
Note: If the engine does not start up after several at-
tempts, see the “Troubleshooting” section.
Note: Always pull the start pull cord out straight. If it
is pulled out at an angle, friction will occur on the lug.
This friction causes the cord to wear through and wear
out faster. Always hold the starter handle when the
cord retracts.
Never let the cord snap back from its extended state.
Note: Do not start the engine in tall grass.
m Attention: If the motor has been switched o, the
trimmer continues running for a few seconds; therefore
keep away from the cutting head of the trimmer until it
comes to a complete standstill!
9. Working instructions
Extension of the cutting thread
Warning! Do not use metal wire or any type of plas-
tic-coated metal wire in the thread coil. This could seri-
ously injure the user.
To lengthen the cutting thread, run the engine at full
throttle and tap the thread coil on the ground. The
thread is automatically lengthened. (g. 41)
The blade on the shield shortens the thread to the per-
missible length. (g. 16)
