www.scheppach.com
20
|
GB
Installing the folded lter (14) (Fig. E)
• Push the lter cage (15) over the folded lter (14) and
place it on the bottom of the machine head (1). (Fig.
E)
• Secure the folded lter (14) with the knurled screw
(18).
Installing the suction hose (13) (Fig. F)
• Connect the suction hose (13) to the corresponding
port, depending on the desired use, on the ash vac-
uum cleaner.
Sucking (Fig. F)
• Connect the suction hose (13) to the suction hose
port (3). To do so, slide the end of the suction hose
(13) with the two nipples into the suction hose port (3).
• Insert the two nipples into the recesses. In the end
position, turn the suction hose (13) in a clockwise di-
rection.
Blowing (Fig. G)
• Connect the suction hose (13) to the blowing function
connection port (9). Slide the end of the suction hose
(13) with the two nipples into the blowing function
connection port (9).
• Insert the two nipples into the recesses. In the end
position, turn the suction hose (13) in a clockwise di-
rection.
Mounting the hose (13), aluminium tube (16) and at
nozzle (17) (Fig. H)
• Push the aluminium tube (16) or the at nozzle (17)
onto the end of the suction hose (13).
8. Operation
m Attention!
Always make sure the device is fully assembled be-
fore commissioning!
m ATTENTION!
Before use, check all connections and the folded l-
ter (14) for a rm and secure connection. The stain-
less steel container (6) and the folded lter (14) must
be absolutely dry.
Switching on/o (Fig. B)
The on/o switch (11) has two settings.
• Switch setting 0: O
• Switch setting I: On
• Undiluted strong acids and alkalis.
• Organic solvents (such as gasoline, paint thinner,
acetone, heating oil).
In addition, these substances can corrode the materials
used on the device.
m WARNING!
This power tool generates an electromagnetic eld dur-
ing operation. This eld can impair active or passive
medical implants under certain circumstances.
In order to prevent the risk of serious or deadly inju-
ries, we recommend that persons with medical implants
consult with their physician and the manufacturer of the
medical implant prior to operating the power tool.
6. Technical data
Mains voltage 220 - 240V~ 50/60 Hz
Power 1300 W
Water tank capacity 20 l
Suction performance 20 kPa
Protection category IPX0
Protection class II
Subject to technical changes!
7. Assembly
m ATTENTION!
Prior to use, ensure that the device has been cor-
rectly and fully assembled.
Installing roller mounts (4) (Fig. D)
• Turn the stainless steel container (6) upside-down
(the machine head (1) must be removed).
• Connect the castor mounts (4) into the cut-outs pro-
vided on the stainless steel container (6). (3x)
Installing the castors (Fig. D)
• Press the three castors (5) into the holes of the roller
mounts (4).
Installing the machine head (1) (Fig. A)
• Place the machine head (1) on the stainless steel
container (6). Secure the machine head (1) with the
locking hooks (8). When installing the machine head
(1), ensure that the locking hooks (8) latch into place
correctly.
