www.scheppach.com
24
|
GB
• Keep your hands away from the working area when
the product is in operation.
7. Technical data
Overall length 820 millimeters
Operating pressure 6.3 bar
Air consumption, min. 160 l/min
Air consumption, max. (at 6.3 bar) 280 l/min
Number of impacts 2100 bpm
Tool receiver 18 millimeters
Hose internal diameter 8 millimeters
Subject to technical changes!
Noise and vibration
m Warning: Noise can have serious eects on your
health. If the machine noise exceeds 85 dB, please
wear suitable hearing protection.
Noise and vibration
The noise and vibration values have been measured
with a standardised measurement process.
Sound pressure level L
pA
86.69 dB
Sound power level L
wA
100.7 dB
Measurement uncertainty K
WA
1.66 dB
Maximum vibration on right handle a
h
15.53 m/s²
Maximum vibration on left handle a
h
16.22 m/s²
Measurement uncertainty K 1.5 m/s²
Wear hearing protection.
Excessive noise can result in a loss of hearing.
Keep the noise level and vibration to a minimum!
• Only use faultless products.
• Maintain and clean the product at regular intervals.
• Adapt your working methods to the product.
• Do not overload the product.
• Have the product checked if necessary.
• Switch the product o if it is not in use.
• Wear protective gloves.
Additional safety instructions
• If necessary, observe special occupational safety or
accident prevention regulations for handling com-
pressors and compressed air tools.
• Make sure that the maximum permissible working
pressure specied in the technical data is not ex-
ceeded.
• Do not overload this tool – use this tool only in the
power range specied in the technical data.
• Use harmless lubricants. Ensure that the workplace
is suciently ventilated. In case of increased wear:
Have the compressed air tool checked and repaired
if necessary.
• Do not use this tool when you are distracted. Stay
alert, watch what you are doing and use common
sense when operating a compressed air tool. Do
not use any tool while you are tired or under the
inuence of drugs, alcohol or medication. A moment
of carelessness when using the tool can result in
serious injuries.
• Keep your work area clean and well-lit. Cluttered or
dark areas invite accidents.
• Keep compressed air universal tools away from
children.
• Do not store tools unprotected outdoors or in damp
conditions.
• Protect the compressed air tool, especially the
compressed air connection and the controls, from
dust and dirt.
6. Residual risks
The product has been built according to state-of-the-
art and the recognised technical safety rules. However,
individual residual risks can arise during operation.
• Lung damage if suitable dust protection mask is not
worn.
• Hearing damage if suitable hearing protection is not
worn.
• Damage to health resulting from hand/arm vibration
if the device is used over an extended period of time
or if it is not properly operated and maintained.
• Furthermore, despite all precautions having been met,
some non-obvious residual risks may still remain.
• Residual risks can be minimised if the “Safety In-
structions” and the “Intended Use” together with the
operating manual as a whole are observed.
• Avoid accidental start-ups of the product.
• Use the tool attachment that is recommended in this
operating manual. This is how to ensure that your
product provides optimum performance.
