Safety instructions 5
1. Safety instructions
Before using the device, please read carefully this user manual. It delivers important information about the device
operations, maintenance and storage.
1.1 General warnings about the device
• Interior and exterior use.
• Respect the measuring ranges of the probes and hoses connected to the device.
• This device has been developed and produced to be sold exclusively to trained and qualied HVACR technicians
and engineers. Appropriate training might be necessary in order to ensure safe use of this instrument. Sauermann
is not responsible for any possible accident during its use.
• Please always use the device in accordance with its intended use and within parameters described in the technical
features in order not to compromise the protection ensured by the device.
• When using the device, the safety of the system integrating the device is the responsibility of the system assembler.
• This device can pose a risk for pacemaker wearers. Respect a distance of at least 10 cm (4") between the device
and the wearer.
• Respect a safety distance with other electronic devices like computers, credit cards or TV screens which could be
damaged by the magnetic eld of the device.
• Only the accessories provided with the device or available as an option must be used.
• Do not use the device if it is damaged or if it operates abnormally. Inspect the device before every use. In case of
doubt, please contact Sauermann’s After-sales service.
• In case of contact with battery/accumulator uid: Rinse the affected areas thoroughly with water and, if neces-
sary, consult a doctor.
• Do not authorize pressures beyond the device limits. Please refer to the technical features described in this user
manual.
• The device must not be exposed to rain or any other humid environments (> 85 %RH) without using a proper
protection.
• Do not use the device next to explosive and corrosives gases, vapours or dust.
• Do not place your ngers in movable zones of the device (articulations).
• The device must not be used in ATEX zones according to applicable standards.
• Do not store the device with solvents. Do not use desiccants. Do not use isopropanol.
• During use, keep inspecting the device and accessories for effective operation and your own safety.
• Do not give this product to a child.
• If the device falls or in case of similar inconveniences, or if an irregular malfunction appears, please send back the
device to Sauermann's After-sales service for a technical check and to ensure your own safety.
1.2 Warnings about the manifolds
• A1 / A2L / A2 / A3 refrigerants compatible.
• Compatible with some B1 refrigerants, see list of refrigerants for details on which refrigerants are compatible. The
device must not be used with ammoniac refrigerant (NH
3
/ R717).
• During maintenance and repair work on refrigeration systems with ammable refrigerants (e.g. category A2L, A2
and A3 of ISO 817), a hazardous atmosphere must always be expected in the immediate vicinity of the system. This
product may only be operated outside the hazardous zone.
• The manifold should be used in a well ventilated area.
• Respect the pressure measuring range (-1 to 60 bar / -14 to 870 psi), especially for systems with refrigerant R744,
as these are often operated at higher pressures.
• Maximum overload pressure: 65 bar (943 psi).
• Open and close valves on the manifold in the correct sequence to avoid any leakage of refrigerant from the system
throughout the commissioning, maintenance and repair period.
• This device has been developed to measure simultaneous parameters including pressure, vacuum and temperature
measurements. It must not be used in any other purpose.
• Always use the hook to attach the manifold to prevent it from falling (risk of breakage) before applying pressure.
• Before each measurement, check that the refrigerant hoses are intact and correctly connected. Do not use any tools
to connect the hoses, only hand-tighten the hoses.
• The user must avoid electrostatic charging by being grounded.
• The user of the manifold shall be protected against electrostatic discharges and discharge from static electricity
from its body by being in contact with grounded metallic object or by using an anti-ESD equipment.
• Always wear protective glasses and gloves when using the device in order to protect your eyes
and skin when operating with refrigerant gases. The vapours of refrigerant gases are extremely
cold. Do not expose your skin to these vapours.
