10.3. F 300
Code Description Possibilities
F 301 Diagnostic of the channel 1:
generation of current or voltage
Display
Generation according to the output
signal
0-10 V 0-5 V 0-20 mA 4-20 mA
0 no generation
1 0 V 0 V 0 mA 4 mA
2 5 V 2.5 V 10 mA 12 mA
3 10 V 5 V 20 mA 20 mA
F 302 Low range of the channel 1 According to the type of transmitter
F 303 High range of the channel 1 According to the type of transmitter
F 311 Diagnostic of the channel 2:
generation of current or voltage
Display
Generation according to the output
signal
0-10 V 0-5 V 0-20 mA 4-20 mA
0 no generation
1 0 V 0 V 0 mA 4 mA
2 5 V 2.5 V 10 mA 12 mA
3 10 V 5 V 20 mA 20 mA
F 312 Low range of the channel 2 According to the type of transmitter
F 313 High range of the channel 2 According to the type of transmitter
F 390 Purge mode ON: activated
OFF: deactivated
F 391 Purge duration From 1 to 60 seconds
F 392 Duration between two purges From 1 to 9999 minutes
F 393 Delay From 1 to 60 seconds
10.4. F 400
Code Description Possibilities
F 400 Activation mode of relay 1 0: None
1: Rising edge
2: Falling edge
3: Monitoring
F 401 Channel selection relay 1 0: Channel 1
1: Channel 2
F 402 Threshold 1 relay 1 setting According to the connected probe
F 403 Threshold 2 or hysteresis relay 1 setting According to the connected probe
F 404 Delay 1 relay 1 setting From 0 to 600 seconds
26
FUNCTIONS RECAP
