Sanus VMF822 handleiding
Handleiding
Je bekijkt pagina 9 van 28
9
06
06
4 6
1
2
3/8 in.
(10 mm)
3 in. (8 cm)
002862.eps
05
CAUTION: Avoid potential personal injury or property damage!
● Mount wall plate
06
directly onto concrete surface (no wall covering)
● Minimum solid concrete thickness: 8 in. (203 mm)
● Minimum concrete block size: 8 x 8 x 16 in. (203 x 203 x 406 mm)
Solid Concrete or Concrete Block InstallationSTEP 2B Attach Wall Plate
3
5
CAUTION: Be sure the anchors
09
are seated flush
with the concrete surface.
CAUTION: Never drill into the mortar
between blocks.
CAUTION: Avoid potential personal injury or property damage!
Improper use could reduce the holding power of the lag screw
07
.
Tighten the lag screws
07
only until they are pulled FIRMLY against the
wall plate
06
. DO NOT over-tighten the lag screws
07
.
06
09
08
07
