14
3
2
1
HEAVY! You may need assistance with this step.
STEP 3 Hang TV onto Wall Plate
1. Position the arm of wall plate assembly
08
so the elbow is bent 90 degrees and pressed against the wall.
2. Hang the TV onto the arm of wall plate assembly
08
by first hooking the top support, then resting the TV into place.
3. Lock the TV to the wall plate assembly
08
with locking screw
10
and washer
11
.
CAUTION: Avoid potential personal injuries and property damage! This locking screw
10
must be installed to secure the TV onto the wall plate assembly
08
.
11
10
Top Support
08
08
08
