EXTEND/RETRACT
ONLY IF NEEDED, adjust the
extension/retraction arm tension with
screw
E
using hex key
11
.
CAUTION: Avoid potential
personal injury or property damage!
DO NOT remove screws
E
, only turn
enough for slight adjustment.
11
SIDE-TO-SIDE SHIFT
HEAVY! You may need
assistance with this step.
1. Remove the TV (See below).
2. Open cover plates
P
.
3. Loosen but do not remove, locking screws
S
.
4. Slide arm
09
to the desired position.
5. Tighten locking screws
S
.
CAUTION: Always make sure both locking
screws
S
are tightened so the TV is securely
fastened to wall plate
06
.
6. Close the cover plates
P
,then hang your TV
(see STEP 3).
For wood stud applications ONLY:
CAUTION:
Avoid potential injuries or property damage!
Do NOT adjust the arm position from center for
concrete applications.
Arm
09
MUST remain centered in wall plate
06
for all
concrete applications!
4
5
21
6
3
09
P
P
P
P
S
S
12
REMOVING THE TV
HEAVY! You may need
assistance with this step.
HEAVY! You may need
assistance with this step.
REMOVING THE ARM
1
1
2
2
3
3
4
09
06
09
12
12
10
09
09
06
12
E
S
P
R
