38 _ Disassembly and Reassembly
SAMSUNG PROPRIETARY. DO NOT COPY OR DISTRIBUTE WITHOUT PERMISSION
SAMSUNG PROPRIETARY. DO NOT COPY OR DISTRIBUTE WITHOUT PERMISSION
Reassembly
Part Figure Description
Thermostats
1. Assemble the thermostat by pushing it.
Yellow&Red
blue green red
2. Assemble the terminals as shown in the picture.
Make sure the Wire harness are not getting
stuck in other parts.
Disassembly
Part Figure Description
Assy Main PCB
1. Remove the Back Cover, and BLDC Motor.
The Assy Kit is located in the blue box.
2. Remove guide wire by removing hooks using
long nose plier and remove 2 screws holding
the Assy kit using (+) screw driver on the right
and pull it out from the set.
3. Separate Cover PCB Main from Assy kit.
(It is easier to pull the PCB out with removing
all the hooks grabbing wires under the Frame)
Be careful not to break the hook.
