Before you start
English52
A
1. Pull the detergent drawer to open.
2. Turn the Dispenser cap (A) counterclockwise to
open.
B
3. Apply an appropriate amount of detergent to the
Dispenser .
- After you finish, put the cap back and turn it
clockwise to close.
C
4. Turn the Dispenser cap (C) anticlockwise to open.
D
5. Apply an appropriate amount of softener to the
Dispenser .
- After you finish, put the cap back and turn it
clockwise to close.
6. Push the detergent drawer to close.
- Push the detergent drawer all the way to the end.
You will hear a click sound when the drawer is
properly closed.
