Installation
English36
STEP 5 Position the drain hose
To a Laundry Tub or Drain Pipe
1. Check the height (A) of your drain system and make
sure the minimum and maximum heights shown
below are met.
Minimum 18 in. (46 cm)
Maximum 96 in. (245 cm)
NOTE
• Make sure to measure the height from the floor
where the Laundry Hub is placed.
• Draining efficiency may be reduced if the drain
system is at the maximum height.
• To prevent the washer from siphoning water, do not
use a drain system below the minimum height.
9
2. Attach the drain hose to the plastic hose guide (B).
*
A
(*): Min. 6 in. (152 mm), Max. 8 in. (203 mm)
3. Route the drain hose to the drain system.
CAUTION
• If using a standpipe, make sure the standpipe and
drain hose connection is not airtight.
• If using a standpipe, make sure the drain hose is
inserted at least 6 in. (152 mm) but no more than 8 in.
(203 mm) into the standpipe.
4. Secure the drain hose with cable ties.
