English18
Installation
Follow these instructions carefully to ensure proper installation of the Laundry Hub and to prevent
accidents when doing laundry.
WARNING
• Certain internal parts are intentionally not grounded and may present a risk of electric shock only
during servicing. Service personnel – Do not contact the following parts while the appliance is
energized: Control board, heat sink, motor, inlet valve and pump.
• This appliance is provided with two power-supply connections to the power supply. Each appliance shall
be connected to an individual branch circuit. The washer and dryer must be on separate circuits.
Unpacking
CAUTION
• Never lay the Laundry Hub down on the floor to remove the packaging material. Always keep the
Laundry Hub in an upright position.
• You must have at least 2 people unpack the Laundry Hub.
1. Lean the Laundry Hub on one side to secure space between the Laundry Hub and the base foam
cushion. Then, place a hand truck underneath the Laundry Hub.
2. Lean the hand truck backwards, and then completely remove the base foam cushion from the Laundry
Hub.
