6_ setting up your washer
setting up your washer
LEVELLING
1. Select the washer installation position.
If the washer is placed near to corner, maintain at least 10cm between the washer and the
wall.
2. Adjust the legs, front, below the washer, to level the washer.
3. The way to level the washer.
Adjust the front below adjusting leg to level the washer, according to the drip marker of
gradienter.
Drip marker Explain
Front side is lower
Back side is lower
Left side is lower
Right side is lower
CONNECTING THE WATER SUPPLY HOSE
1. Remove the adaptor from the water
supply hose.
5. Connect the other end of the water
supply hose to the inlet water valve
at the back of the washer.
Screw the hose clockwise all the
way in.
2. First, using a “+” type screw driver,
loosen the four screws on the
adaptor.
Next, take the adaptor and turn
part(b) following the arrow for gap
about 5mm between them.
5-1.Connect the other end of the
water supply hose to the inlet
water valve at the top of the
washer.
Screw the hose clockwise all the
way in.
3. Connect adaptor to the water tap
by tightening the screws firmly.
Then, turn part (b) following the
arrow and put (a) and (b)together.
a
b
Ifthe water tap is a screw type,
assemble a water supply hose that fits
to the tap as shown.
4. Connect the water supply hose to
the adaptor. Pull down the part (c)
of the water supply hose .
When the part (c)is released, the
hose is automatically connected to
the adaptor making a ‘click’ sound.
c
After completing connection, if water leaks from the
hose,then repeat the same steps.
Use the most conventional type of faucet for water supply
In case the faucet is square or too big, remove the spacing
ring before inserting the faucet into the adaptor.
Loosen Lock
WA90GP-DC68-02572C-EN-00.indd 6 2009-4-30 14:06:52
