18_ installation & maintenance
HOW TO CONNECT THE DRAIN HOSE
IN CASE OF PUMP-DRAINED WASHER
Take out the cap-hose and connect the
outlet-hose.
Be sure to join tightly the drain hose into the
drainoutlet on the back of the machine.
Be sure to join tightly the drain hose into
the drain-outlet on the side of the machine.
Install the drain hose in the position of about
90~100cm above the ground.
Cautions when inserting the drain hose(in case of general washer)
1. Don’t exceed more than 3m when the
drain hose is used by connecting with
other hoses.
2. Be careful to drain water out at the end of
the drain hose.
3. The doorsill shoudn’t be more than
5cm.
4. Don’t install the drain hose underneath the
wash machine.
connecTing The Drain hose
After pressing the joint ring(a), insert the drain
hose(b) to drain direction.
installation & maintenance
90~100cm
cap-hose
Less than 3 m
Less than 3 m
Less than 5 cm
(a)
(b)
