English - 13
7. TV Installation
Mounting the TV on a wall
If you mount this TV on a wall, follow the instructions exactly as set out by the manufacturer. Un-
less it is correctly mounted, the TV may slide or fall and cause serious injury to a child or adult and
serious damage to the TV.
Formodelsprovidingwallmountadapters,installthemasshowninthegurebelowbeforeinstallingthewallmount
kit.
N Refer to the installation manual included with the Samsung wall mount kit.
TV
TV
Wall mount
bracket
Wall mount
bracket
C
C
Wall mount Adapter
Wall mount Adapter
Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you choose to
install the wall mount on your own.
To order the wall mount kit, contact Samsung Customer Care.
Youcaninstallyourwallmountonasolidwallperpendiculartotheoor.Beforeattachingthewallmounttosurfaces
other than plaster board, contact your nearest dealer for additional information. If you install the TV on a ceiling or
slanted wall, it may fall and result in severe personal injury.
Standard dimensions for wall mount kits are shown in the table below.
If you are installing a third-party wall mount, note that the length of the screws you can use to attach the TV to the
wall mount is shown in column C in the table below.
TV size in
inches
VESA screw hole specs
(A x B) in millimeters
C (mm) Standard Screw Quantity
78 600 x 400 43 – 45 M8 4
