10
S27DG50* / S32DG50*
―
Disassembly is the reverse order of assembly.
1
Check the direction of the arrow on the stand base. Align the direction of the arrow on the stand base with the front direction of the stand
neck, and then insert the stand neck from top to bottom.
Turn the stand neck clockwise to fasten it to the base. Lift the stand slightly and check that the PUSH button on the bottom of the base
protrudes.
2 3
4
Push the assembled stand into the main body in the direction of the
arrow as shown in the figure.
Confirm that the stand is tightly fastened. If
has not been fully
lowered, lower it while holding it with your hand.
Attach the COVER-REAR TOP to the rear of the monitor, as shown in the figure. Stand up the monitor as shown in the figure.
Separating the stand neck from the stand base
5
Stand assembly is complete. Caution
Do not arbitrarily remove the panel
film. If not observed, the warranty
service may be restricted.
Lift the assembled stand slightly and press the PUSH button on the bottom of the base.
While holding down the PUSH button, turn the stand neck anticlockwise to remove it.
