The TV won’t turn on.
• Make sure that the power cord is securely plugged into
the product and the wall outlet.
• Make sure that the wall outlet is working and the remote
control sensor at the bottom of the TV is lit and glowing
a solid red.
• Try pressing the TV Controller button at the bottom of the
TV to make sure that the problem is not with the remote
control. If the TV turns on, refer to "The remote control
does not work".
The remote control does not work.
• Check if the remote control sensor at the bottom of the
TV blinks when you press the
button on the remote
control.
– H5***F/F6***F/U7***F/U8***F/Q6F/QEF1: If it does
not blink, replace the remote control's batteries. Make
sure that the batteries are installed with their poles
(+/–) in the correct direction. Alkaline batteries are
recommended for longer battery life.
– Other models: When the remote's battery is
discharged, charge the battery using the USB charging
port (C-type), or turn over the remote to expose the
solar cell to light.
• Try pointing the remote directly at the TV from 1.5-1.8 m
away.
• If your TV came with a Samsung Smart Remote (Bluetooth
Remote), make sure to pair the remote to the TV. To pair
a Samsung Smart Remote, press the
and buttons
together for 3 seconds.
Eco Sensor and screen brightness
(except for H5***F, F6***F)
Eco Sensor adjusts the brightness of the TV automatically.
This feature measures the light in your room and optimises
the brightness of the TV automatically to reduce power
consumption. If you want to turn this off, go to
> left
directional button > Settings > All Settings > General
& Privacy > Power and Energy Saving > Brightness
Optimisation.
• The eco sensor is located at the bottom of the TV. Do
not block the sensor with any object. This can decrease
picture brightness.
05 Specifications and Other
Information
Specifications
Display Resolution
QN9**F: 7680 x 4320
F6***F: 1920 x 1080
H5***F: 1366 x 768
Other models: 3840 x 2160
Sound (Output)
H5***F: 10 W
F6***F (24"-32"): 10 W, F6***F (40"): 20 W
U7***F/U8***F/Q6F/Q7F/QEF1/Q8F/QN7*F/QN1EF/S85F: 20 W
QN80F: 30 W, QN85F: 40 W
S90F (42"): 20 W, S90F (48"-83"): 40 W
S92F/S93F/S94F (48"-83"): 60 W
QN9*F (43"): 20 W, QN9*F (50"): 40 W
QN9*F (55"-115"): 60 W
S95F/QN900F: 70 W
QN990F (65"-85"): 90 W, QN990F (98"): 120 W
LS03FW: 40 W
LS03FA (43"-50"): 20 W, LS03FA (55"-65"): 40 W
Operating Temperature
10 °C to 40 °C (50 °F to 104 °F)
Operating Humidity
10 % to 80 %, non-condensing
Storage Temperature
-20 °C to 45 °C (-4 °F to 113 °F)
Storage Humidity
5 % to 95 %, non-condensing
Notes
• This device is a Class B digital apparatus.
• For information about the power supply, and more
information about power consumption, refer to the
information on the label attached to the product.
– On most models, the label is attached to the back of
the TV. (On some models, the label is inside the cover
terminal.)
– On One Connect Box models, the label is attached to
the bottom of the One Connect Box.
English - 7
English
