The TV won’t turn on.
• Make sure that the power cord is securely plugged into
the product and the wall outlet.
• Make sure that the wall outlet is working and the remote
control sensor at the bottom of the TV is lit and glowing
a solid red.
• Try pressing the TV Controller button at the bottom of the
TV to make sure that the problem is not with the remote
control. If the TV turns on, refer to "The remote control
does not work".
The remote control does not work.
• Check if the remote control sensor at the bottom of the
TV blinks when you press the
button on the remote
control.
– H5***F/HE50EF/F6***F/FE60EF/U7***F/U8***F/
UE8**F/QEF1/QE1F: If it does not blink, replace
the remote control's batteries. Make sure that the
batteries are installed with their poles (+/–) in the
correct direction. Alkaline batteries are recommended
for longer battery life.
– Other models: When the remote's battery is
discharged, charge the battery using the USB charging
port (C-type), or turn over the remote to expose the
solar cell to light.
• Try pointing the remote directly at the TV from 1.5-1.8 m
away.
• If your TV came with a Samsung Smart Remote (Bluetooth
Remote), make sure to pair the remote to the TV. To pair
a Samsung Smart Remote, press the
and buttons
together for 3 seconds.
Eco Sensor and screen brightness
(except for H5***F, F6***F)
Eco Sensor adjusts the brightness of the TV automatically.
This feature measures the light in your room and optimises
the brightness of the TV automatically to reduce power
consumption. If you want to turn this off, go to
> left
directional button > Settings > All Settings > General
& Privacy > Power and Energy Saving > Brightness
Optimisation.
• The eco sensor is located at the bottom of the TV. Do
not block the sensor with any object. This can decrease
picture brightness.
How to turn on and off the Microphone
Type A Type B
Type C Type D
: On/Off Switch
You can turn on or off the microphone by using the switch at
the bottom or rear bottom of the TV. If microphone is turned
off, All voice and sound features using microphone are not
available.
• This function is supported only in Q8F (except for 32Q8F)/
QN7*F/QN*EF/QN8*F/QN9*F/QN9**F/S8*F/S9*F/The
Frame.
• The position and shape of the microphone switch may
differ depending on the model.
• During analysis using data from the microphone, the data
is not saved.
04 Troubleshooting and
Maintenance
Troubleshooting
For more information, refer to "Troubleshooting" in the User
guide.
(F6***F/H5***F:
> left directional button > Settings >
Support > Open User guide > Troubleshooting)
(Other models:
> left directional button > Settings
> Support > Tips and User Guides > Open User guide >
Troubleshooting)
If none of the troubleshooting tips apply, please visit "www.
samsung.com" and click Support or contact the Samsung
service centre.
• This panel is made up of sub pixels which require
sophisticated technology to produce. There may be,
however, a few bright or dark pixels on the screen. These
pixels will have no impact on the performance of the
product.
• To keep your TV in optimum condition, upgrade to the
latest software. Use the Update Now or Auto update
functions on the TV's menu (
> left directional button >
Settings > Support > Software Update > Update Now or
Auto update).
English - 7
