English 21
Installation instructions
Step 3. Convert to lp gas (optional)
All new gas ranges are shipped from the factory set up to use natural gas.
Any Samsung gas range can be converted to use LP gas. Refer to page 55 in the
User Manual to contact a qualied service technician.
The conversion process should only be performed by a qualied LP gas installer.
Conversion instructions and LP orices will be supplied with the LP conversion kit.
The conversion to LP requires all burner orices to be changed (5 surface burners
and 2 oven burners).
In addition, the nozzle on the gas pressure regulator needs to be reversed.
All replaced orices must be left with the consumer, including the instructions and
retrot sizes and orice indication.
Checking the ame quality all burner after converting to lp gas.
Step 4. Install the anti-tip device
WARNING
To reduce the risk of tipping, the appliance must be secured by properly installing
the anti-tip device packed with the appliance.
• All ranges can tip, resulting in personal injury.
• Tipping ranges can cause burns from spills, personal injury, and/or death.
• To prevent accidental tipping, install and check the anti-tip bracket following the
instructions and template supplied with the bracket.
An anti-tip bracket and screws, installation
instructions, and template are shipped with
every range (PN DG94-00870B).
The instructions include information
necessary to complete the installation
of the anti-tip bracket. Read and follow
the instructions on the sheet and use the
template for anti-tip bracket installation. If
not properly installed, the range could be
tipped by you or a child standing, sitting, or
leaning on an open oven door.
*approximately
21
/
32
" (16.5 mm)
Screw must enter
wood or concrete
Anti-Tip
bracket
*NOTE: To install the Anti-Tip
bracket, release the leveling
leg. A minimum clearance of
21
/
32
" (16.5 mm) is required
between the range bottom
and the kitchen oor.
To check if the bracket is installed and engaged properly, remove storage drawer
and look underneath the range to see that the leveling leg is engaged in the
bracket. Carefully tip the range forward. The bracket should stop the range within
4 inches (10.2 cm) of tipping. If it does not, the bracket must be reinstalled.
