Installing the unit
3. Cautions about MCU installation.
When xing the unit at the upper place using suspension bolts, use a nut and washer to vertically fasten the unit.
There are four spots to x the suspension bolts. Make sure every spot is xed.
The upper and the lower side of MCU is distinguished, so be careful not to turn the unit upside down when installing the
unit. Otherwise, noise may be generated or the product may be damaged.
4. How to connect the pipe line.
Nut
Washer
Anti vibration
rubber
Fasten the nut rmly
764 (Between the locations of suspension bolts)
224
224
(Unit :mm)
Low pressure gas pipe connection (Flange)
O-ring
Insert O-ring into the gap when connecting
the ange
High pressure gas pipe connection (Brazing)
Liquid pipe connection (Flare)
Pipe connection from outdoor unit
Pipe connection to indoor unit
Gas pipe (Flare)Liquid pipe(Flare)
When installing MCU, use the pattern sheet for installation that is provided with the product.
When brazing the high pressure gas pipe, protect the product with the ame-proof sheet.
Braze the ange of the low pressure gas pipe before connecting it to MCU body.
Make sure to insert the provided O-ring in the gap.
<Location and intervals of xed suspension bolts> <Fixing the bolt>
Protect with
wet towel when
brazing
