Rear Panel View
Apparatus Claims of U.S. Patent Nos.
4,631,603,4,577,216,4,819,098 and 4,907,093
licensed for linited viewing uses only.
AVIS :
DISCONNECT THE UNIT FROM THE MAINS
BEFORE REMOVING THE COVER.
RISK OF ELECTRIC SHOCK
CO NOT OPEN
RISQUE DE CHOC ELECTRIQUE-NE PAS
OUVRIR.
CAUTION
MAX-KD100
AH64-01703L
1
2
3
4
5
6
1. FM Aerial Connector Terminal
2. AM(MW)/LW Aerial Connector Terminal
3. Digital Out Jack
4. MAIN Speaker Connector Terminals
5. VIDEO-Output
6. AUX-Input
Rear Panel View
(MAX-KD120)
VIDEO
OUT
Apparatus Claims of U.S. Patent Nos.
4,631,603,4,577,216,4,819,098 and 4,907,093
licensed for linited viewing uses only.
AVIS :
DISCONNECT THE UNIT FROM THE MAINS
BEFORE REMOVING THE COVER.
RISK OF ELECTRIC SHOCK
CO NOT OPEN
RISQUE DE CHOC ELECTRIQUE-NE PAS
OUVRIR.
CAUTION
MAX-KD120
AH64-01703M
1
2
3
4
5
6
7
1. FM Aerial Connector Terminal
2. AM(MW)/LW Aerial Connector Terminal
3. Digital Out Jack
4. MAIN Speaker Connector Terminals
5. Subwoofer Speaker Connector Terminals
6. VIDEO-Output
7. AUX-Input
