11
S49AG95*N
x 4
1
2
Connect the corresponding cables. Collect cables and then align them with the centre groove of COVER REAR SUB.
Assembly the COVER REAR SUB on the rear of the product.
3 4 5 6
Remove the COVER STAND BODY REAR
by pulling it in the direction as shown
in the figure.
Insert the stand base into the stand
neck in the direction as shown in the
figure.
Place the stand neck on the monitor as
shown in the figure.
Fasten the screws at the top of the
stand neck.
7
8 9 10
Disassemble the COVER-REAR TOP. Assemble the COVER-REAR TOP to the stand
neck as shown in the figure. Rotate the COVER-REAR TOP clockwise.
Place the corresponding cables into
the stand-neck holder. Do not stretch
the cable. Three cables in one holder is
recommended.
Push the COVER STAND BODY REAR in
the direction as shown in the figure.
Stand up the monitor as shown in the
figure.
11
12
Remove the package. Move the product onto the table. At this time, hold the cables together not to be
stuck under the stand.
Caution
Do not arbitrarily remove the panel
film. If not observed, the warranty
service may be restricted.
