Following the repair by a non-authorised service provider,
self-repair or non-professional repair of the product,
Samsung is not liable for any damage to the product, any
injury or any other product safety issue caused by any
attempt to repair the product which does not carefully follow
these repair and maintenance instructions. Any damage to
the product caused by an attempt to repair the product by
any person other than a Samsung certified service provider
will not be covered by the warranty.
Decreasing power consumption
When you shut the TV off, it enters Standby mode. In Standby
mode, it continues to draw a small amount of power. To
decrease power consumption, unplug the power cord when
you don't intend to use the TV for a long time.
Hereby, Samsung declares that this radio equipment is in
compliance with Directive 2014/53/EU and the relevant UK
statutory requirements.
The full text of the declaration of conformity is available at
the following internet address:
http://www.samsung.com go to Support and enter the model
name.
This equipment may be operated in all EU countries and in
the UK.
The 5 GHz and 6 GHz WLAN(Wi-Fi) function of this equipment
may only be operated indoors.
RF max transmitter power :
[QN9**F]
100 mW at 2.4 GHz - 2.4835 GHz,
200 mW at 5.15 GHz - 5.25 GHz,
100 mW at 5.25 GHz - 5.35 GHz & 5.47 GHz - 5.725 GHz,
25 mW at 5.725 GHz - 5.85 GHz (QN990F only),
200 mW at 5.945 GHz - 6.425 GHz.
[S9*F/S8*F/QN9*F/QN8*F/QN7*F/QN1EF/Q8F/Q7F/QEF1/
Q6F/U8***F/U7***F/F6***F/H5***F]
100 mW at 2.4 GHz - 2.4835 GHz,
200 mW at 5.15 GHz - 5.25 GHz,
100 mW at 5.25 GHz - 5.35 GHz & 5.47 GHz - 5.725 GHz.
[The Frame(LS03FA)]
100 mW at 2.4 GHz - 2.4835 GHz,
200 mW at 5.15 GHz - 5.25 GHz,
100 mW at 5.25 GHz - 5.35 GHz & 5.47 GHz - 5.725 GHz,
100 mW at 61 GHz - 61.5 GHz.
[The Frame(LS03FW)]
100 mW at 2.4 GHz - 2.4835 GHz,
200 mW at 5.15 GHz - 5.25 GHz,
100 mW at 5.25 GHz - 5.35 GHz & 5.47 GHz - 5.725 GHz,
25 mW at 5.725 GHz - 5.85 GHz,
200 mW at 5.945 GHz - 6.425 GHz,
100 mW at 61 GHz - 61.5 GHz.
Operating Temperature
10 °C to 40 °C (50 °F to 104 °F)
Operating Humidity
10 % to 80 %, non-condensing
Storage Temperature
-20 °C to 45 °C (-4 °F to 113 °F)
Storage Humidity
5 % to 95 %, non-condensing
Notes
• This device is a Class B digital apparatus.
• For information about the power supply, and more
information about power consumption, refer to the
information on the label attached to the product.
– On most models, the label is attached to the back of
the TV. (On some models, the label is inside the cover
terminal.)
– On One Connect Box models, the label is attached to
the bottom of the One Connect Box.
• Typical power consumption is measured according to IEC
62087.
• To connect a LAN cable, use a CAT 7 (*STP type) cable for
the connection. (100/10 Mbps)
* Shielded Twisted Pair
• The images and specifications of the Unpacking and
Installation Guide may differ from the actual product.
• Figures and illustrations in this Simple User Guide are
provided for reference only and may differ from the actual
product appearance. Product design and specifications
may change without notice.
• The use of this product is restricted to and permanently
located in buildings, trains with metal coated windows
and aircraft. (QN990F, The Frame(LS03FW) only)
• Operation of this product shall be limited to indoor use
only. (QN900F only)
An administration fee may be charged in the following
situations:
(a) An engineer is called out at your request, but it is
found that the product has no defect (i.e., where the user
manual has not been read).
(b) You bring the unit to the Samsung service centre, but
it is found that the product has no defect (i.e., where the
user manual has not been read).
You will be informed of the administration fee amount before
a technician visits.
Please visit samsung.com/support to find futher information
about external power adapter and remote control associated
with EU Ecodesign directive - ErP regulation
English - 8
