ENGLISH
COOKING BY CONVECTION
The convection mode enables you to cook food in the same way as in
a traditional oven. The microwave mode is not used. You can set the
temperature, as required, in a range varying from 40°C to 200°C in eight
preset levels. The maximum cooking time is 60 minutes.
If you wish to Fast Preheat the oven, see the left side .
• Alwaysuseovengloveswhentouchingtherecipientsintheoven,
as they will be very hot.
• Youcangetbettercookingandbrowning,ifyouusethelowrack.
Check that the heating element is in the horizontal position and that the
turntable is in position. Open the door and place the recipient on the low
rack and set on turntable.
1. Press the Convection ( ) button.
Result : The following indications are displayed:
(convection mode) 200°C
(temperature)
2. Press the Convection ( ) button once or more
times to set the temperature.
(Temperature : 200, 180, 160, 140, 100, 40°C)
3. Select the cooking time by pressing the 10min,
1min and 10s buttons.
Be careful, Grill heater may work intermittently while the convection
mode is operating.
4. Press the Start ( ) button.
Result : Cooking starts:
• Thedisplaytimesare8seconds
for the preset cooking time and 2
seconds for the preset temperature in sequence.Ex) 30
minutes of cooking time at 200°C
(displayed for 8 seconds) (displayed for 2 seconds)
• Whencookinghasnished,theovenwillbeepandash
“0” four times. The oven will then beep one time per
minute.
If you would like to know the current temperature of oven cavity, press
Fast Preheat (
) button.
CHOOSING THE HEATING ELEMENT POSITION
The heating element is used when grilling. There is only one position listed.
We need to tell consumers when it should be placed in the vertical position.
• Horizontal position for grilling or combined microwave + grill cooking
Only change the position of the heating element when it is cold and do
not apply excessive force when placing it in the vertical position.
To set the heating
element to the...
Then...
Horizontal position
(grill or combined
microwave + grill).
• Pull the heating element
towards you.
• Push it upwards until it is
parallel with the roof of the
oven.
When cleaning the upper part inside the cavity, it will be
convenient to turn heater downward by 45 ° and clean
it.
CHOOSING THE ACCESSORIES
Traditional convection cooking does require cookware.
You should, however, use only cookware that you would use in your normal
oven.
Microwave-safe containers are not usually suitable for convection cooking;
don’t use plastic containers, dishes,paper cups, towels,
etc.
If you wish to select a combined cooking mode
(microwave and grill or convection), use only recipients
that are microwave-safe and oven-proof.
• For further details on suitable cookware and utensils, refer to the
Cookware Guide on page 31.
