Installation
Assembling the Stand base (C*FG70* model only)
1 2 3 4
A
B
5
Place the protective Styrofoam (cushion)
included in the package on the floor and
place the product facing down on the
Styrofoam, as shown in the image.
―
Make sure to use the styrofoam (cushion)
that came with the monitor.
Attach the stand to the back of the
monitor, in the direction of the arrow.
Use the screws on the stand to tightly
fasten.
Detach the COVER REAR SUB from the
COVER REAR TOP in the direction as
shown in the figure.
On the back of the monitor, align and
push the COVER REAR TOP in the groove
in the direction of the arrow.
6 7 8 9 10
Push the COVER REAR TOP in the
direction of the arrows.
On the back of the monitor, align and
push the COVER REAR SUB in the groove
in the direction of the arrow.
While pressing down with one hand on
the lower styrofoam layer, lift the stand's
neck with the other hand.
Attach the stand base to the neck, as
shown in the image. Make sure there
is no gap between the stand neck and
base.
Attach the stand base to the stand neck,
and then fasten the two screws on the
base to tightly fix it.
