22
Owner’s Manual &
Installation Manual
BEFORE PERFORMING ANY
ELECTRICAL WORK, READ THESE
REGULATIONS
1. All wiring must comply with local and
national electrical codes, regulations and
must be installed by a licensed electrician.
2. All electrical connections must be made
according to the Electrical Connection
Diagram located on the panels of the
indoor and outdoor units.
3. If there is a serious safety issue with the
power supply, stop work immediately.
Explain your reasoning to the client, and
refuse to install the unit until the safety
issue is properly resolved.
4. Power voltage should be within 90-
110% of rated voltage. Insufcient power
supply can cause malfunction, electrical
shock, or re.
5. If connecting power to xed wiring,
install a surge protector and main power
switch with a capacity of 1.5 times the
maximum current of the unit.
6. If connecting power to xed wiring,
a switch or circuit breaker that
disconnects all poles and has a contact
separation of at least 1/8in (3mm) must
be incorporated in the xed wiring.
The qualied technician must use an
approved circuit breaker or switch.
7. Only connect the unit to an individual
branch circuit outlet. Do not connect
another appliance to that outlet.
8. Make sure to properly ground the air
conditioner.
9. Every wire must be rmly connected.
Loose wiring can cause the terminal to
overheat, resulting in product malfunction
and possible re.
10. Do not let wires touch or rest against
refrigerant tubing, the compressor, or
any moving parts within the unit.
11. If the unit has an auxiliary electric heater,
it must be installed at least 1 meter (40in)
away from any combustible materials.
12. To avoid getting an electric shock, never
touch the electrical components soon
after the power supply has been turned
off. After turning off the power, always
wait 10 minutes or more before you
touch the electrical components.
WARNING
BEFORE PERFORMING ANY
ELECTRICAL OR WIRING WORK,
TURN OFF THE MAIN POWER TO THE
SYSTEM.
Step 6: Connect signal cable
The signal cable enables communication
between the indoor and outdoor units. You
must rst choose the right cable size before
preparing it for connection.
Cable Types
●
Indoor Power Cable
(if applicable):
H05VV-F or H05V2V2-F
●
Outdoor Power Cable:
H07RN-F
●
Signal Cable:
H07RN-F
Minimum Cross-Sectional Area of Power
and Signal Cables (For reference)
Rated Current
of Appliance (A)
Nominal Cross-Sectional
Area (mm²)
> 3 and ≤ 6 0.75
> 6 and ≤ 10 1
> 10 and ≤ 16 1.5
> 16 and ≤ 25 2.5
> 25 and ≤ 32 4
> 32 and ≤ 40 6
CHOOSE THE RIGHT CABLE SIZE
The size of the power supply cable,
signal cable, fuse, and switch needed is
determined by the maximum current of the
unit. The maximum current is indicated on
the nameplate located on the side panel of
the unit. Refer to this nameplate to choose
the right cable, fuse, or switch.
