7
Owner’s Manual &
Installation Manual
Unit Specications and Features
Indoor unit display
NOTE:
Different models have different front panel and display window. Not all the indicators describing
below are available for the air conditioner you purchased. Please check the indoor display window of
the unit you purchased.
Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit may be
slightly different. The actual shape shall prevail.
Front Panel
Power Cable (Some Units)
Remote Control
fresh
fresh
fresh
defrost
defrost
defrost
timer
timer
timer
run
run
run
Display window (A) Display window (B) Display window (C) Display window (D)
Remote Control Holder
(Some Units)
Louver
“
fresh
” when Fresh feature is activated (some units)
“
defrost
” when defrost feature is activated.
“
run
” when the unit is on.
“
timer
” when TIMER is set
“ ” when Wireless Control feature is activated (some units)
“ ” Displays temperature, operation feature and
Error codes:
When ECO function (some units) is activated, the
’ ’ illuminates gradually one by one as --
-- --set temperature -- ...... in one second interval.
“ ” for 3 seconds when:
● TIMER ON is set (if the unit is OFF, “ ” remains on when TIMER ON
is set)
● FRESH, SWING, TURBO, or SILENCE feature is turned on “ ” for
3 seconds when:
● TIMER OFF is set
● FRESH, SWING, TURBO, or SILENCE feature is turned off
“ ” when anti-cold air feature is turned on
“ ” when defrosting (cooling & heating units)
“ ” when unit is self-cleaning (some units)
“ ” when 8ºC heating feature is turned on (some units)
Display Code
Meanings
