Installation Summary - Indoor Unit
1
2
3
4
12cm
(4.75in)
2.3m (90.55in)
12cm
(4.75in)
15cm (5.9in)
STEP
8
4 5
6
7
8
9
Select Installation Location
Drill Wall Hole
Prepare Drain Hose
Determine Wall Hole Position
Connect Piping
Mount Indoor Unit
Wrap Piping and Cable
(not applicable for some locations in the US)
Attach Mounting Plate
Connect Wiring
(not applicable for some locations
in the US )
12cm
(4.75in)
12cm
(4.75in)
15cm (5.9in)
2.3m (90.55in)
