Handleiding
Je bekijkt pagina 4 van 54
3English
Installation 33
Safety Information on Installation 33
Preparation 35
Step 1.1 Choosing the installation location
Step 1.2 Packing and Unpacking
Step 1.3 Checking and preparing accessories and tools
Step 1.4 Drilling a hole through the wall
Step 1.5 Taping the pipes, cables, and drain hose
Indoor Unit Installation 40
Step 2.1 Disassembling the cover panel
Step 2.2 Disassembling the installation plate
Step 2.3 Connecting the power and communication cables (assembly cable)
Step 2.4 Optional: Extending the power cable
Step 2.5 Installing and connecting the drain hose
Step 2.6 Optional: Extending the drain hose
Step 2.7 Optional: Changing the direction of the drain hose
Step 2.8 Installing and connecting the assembly pipes to the refrigerant pipes (assembly pipe)
Step 2.9 Shortening or extending the refrigerant pipes (assembly pipe)
Step 2.10 Fixing the installation plate
Step 2.11 Fixing the indoor unit to the installation plate
Step 2.12 Assembling the cover panel
Outdoor Unit Installation 48
Step 3.1 Fixing the outdoor unit in place
Step 3.2 Connecting the power and communication cables and the refrigerant pipes
Step 3.3 Evacuating the air
Step 3.4 Adding refrigerant
Installation Inspection 51
Step 4.1 Performing the gas leak tests
Step 4.2 Running the Smart Install mode
Step 4.3 Performing final check and trial operation
Bekijk gratis de handleiding van Samsung AR18KVPDEWK, stel vragen en lees de antwoorden op veelvoorkomende problemen, of gebruik onze assistent om sneller informatie in de handleiding te vinden of uitleg te krijgen over specifieke functies.
Productinformatie
| Merk | Samsung |
| Model | AR18KVPDEWK |
| Categorie | Airco |
| Taal | Nederlands |
| Grootte | 6998 MB |
