Unit Parts
NOTE: The installation must be performed in accordance with the requirement of local and
national standards. The installation may be slightly different in different areas.
(1) (2)
1
2
3
4
6
7
8
9
10
11
3
1
2
4
5
6
7
8
11
5
Air-break switch
Wall Mounting Plate
Front Panel
Power Cable (Some Units)
Louver
Functional Filter (On Back
of Main Filter - Some
Units)
Drainage Pipe
Signal Cable
Refrigerant Piping
Remote Controller
Remote controller Holder
(Some Units)
Outdoor Unit Power Cable
(Some Units)
NOTE ON ILLUSTRATIONS
Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit
may be slightly different. The actual shape shall prevail.
