ENGLISH
OPENING THE FRONT PANEL
Tightly grab front side of the front panel and lift up the panel to open. Then slightly push the panel up until
the panel is hanged over the hooks of the unit.
Power button, Room temperature sensor
You may locate the Power button on the right bottom side of the air conditioner. If the front
panel is open, you can check the room temperature sensor.
You can turn on the air conditioner without the remote control by pressing the
Power button.
The room temperature sensor measures indoor room temperature.
Make sure room temperature and humidity sensor does not get damaged.
CHECKING THE OUTDOOR UNIT
AQ09E Series/AQ12E Series AQ18E Series
AQ24E Series
Air Inlet (Rear)
Connection Valve
Air Outlet
Air Inlet (Rear)
Connection Valve
Air Outlet
Power button
Room temperature
sensor
Air Inlet (Rear)
Connection Valve
Air Outlet
CAUTION
AQ09E series_IB_E_30742_2.03.10.indd 11 2010-2-3 14:53:52
