18
Refrigerant pipe installation
English
Installation Procedure
H/R
When all the following conditions are met, install the main liquid pipe that is one step smaller to reduce piping load and the amount of
refrigerant.
Note that the refrigerant for the main liquid pipe must be added by the specified amount upon reduction.
Condition 1: In case the length for vertical piping is less than 40 m
Condition 2: Max. length A ≥ Max. pipping length/{1 - (vertical piping length * 0,015)}
※ Max. piping length: Piping length between the outdoor unit and the farthest indoor unit (m)
• Length allowed to reduce the diameter of liquid pipe, A (equivalent length)
• When piping is installed with reduction of the diameter of liquid pipe, Please set option ‘reduction of the diameter of liquid pipe’.
Capacity
(HP)
Below 90 m Over 90m
Capacity
(HP)
Below 90 m Over 90m
Pipe
diameter
Max.
length (m)
Pipe
diameter
Max.
length (m)
Pipe
diameter
Max.
length (m)
Pipe
diameter
Max.
length (m)
8
This capacity is not supported.
54 15.88 40 19.05 130
10
This capacity is not supported.
56 15.88 40 19.05 120
12 9.52 50 12.7 200 58 15.88 40 19.05 120
14 9.52 40 12.7 190 60 15.88 40 19.05 110
16 9.52 30 12.7 150 62 19.05 90 22.22 200
18 12.7 90 15.88 200 64 19.05 90 22.22 200
20 12.7 90 15.88 200 66 19.05 90 22.22 200
22 12.7 80 15.88 200 68 19.05 90 22.22 200
24 12.7 70 15.88 200 70 19.05 80 22.22 190
26 15.88 90 19.05 200 72 19.05 80 22.22 180
28 15.88 90 19.05 200 74 19.05 70 22.22 170
30 15.88 90 19.05 200 76 19.05 70 22.22 160
32 15.88 90 19.05 200 78 19.05 70 22.22 150
34 15.88 90 19.05 200 80 19.05 60 22.22 150
36 15.88 90 19.05 200 82 19.05 60 22.22 140
38 15.88 90 19.05 200 84 19.05 60 22.22 130
40 15.88 80 19.05 200 86 19.05 50 22.22 130
42 15.88 70 19.05 200 88 19.05 50 22.22 120
44 15.88 70 19.05 200 90 19.05 50 22.22 120
46 15.88 60 19.05 180 92
This capacity is not supported.
48 15.88 60 19.05 170 94
This capacity is not supported.
50 15.88 50 19.05 150 96
This capacity is not supported.
52 15.88 50 19.05 140 98
This capacity is not supported.
e.g. In case of the site for 20HP, Max. piping length of 140 m (Horizontal piping length of 120 m & Vertical piping length of 20 m):
Max. length A ≥ Max. piping length/{1 - (Vertical piping length * 0.015)}
200 m ≥ 140 m/{1 - (20 * 0.015)} = 140 m/0.7 = 200 m
Thus, the Max. piping length of 140 m (Horizontal piping length of 120 m & Vertical piping length of 20 m) can be allowed.
Accordingly, horizontal piping of 120 m + vertical piping of 20 m (140 m in total) can be installed.
