Installation Procedure
Capacity Index (kW) 1.5 1.7 2.2 2.5 2.8 3.2 3.6 4 4.5 5.6 6 7.1 8.2 9 9.3 11.2 12.8 14 16 17 18 22 22.4 28 32 50
500
CMH
1000
CMH
Capacity Index (MBH)
5 6 7 8 9 11 12 14 15 18 20 24 27 30 32 36 42 48 54 58 60 72 76 96 110 170
HSP duct
(with drain pump)
(AM***ANHDCH/**)
0.68 0.68 0.68 0.84 0.84
OAP duct
(AM****NEP*H/**)
0.68 1.18 1.18
Floor Standing
(AM****NFDEH/**)
(AM****NPDKH/**)
0.22 0.32 0.32 0.69 1.85
Console
(AM****NJDEH/**)
0.16 0.27 0.27 0.27 0.27
Ceiling
(AM****NCD*H/**)
0.39 0.39 0.56 0.95
Wall mounted
(AM***KNTDEH/**)
0.24 0.24 0.32 0.32 0.49 0.49 0.49
Wall mounted
(AM***TNADKH/**)
0.23 0.23 0.32 0.32 0.48 0.48 0.48 0.64
Wall mounted
(with EEV)
(AM***NQD*H/**)
0.24 0.24 0.32 0.32 0.49 0.49 0.49 0.64 0.68
Wall mounted
(with EEV)
(AM***TNVDKH/**)
0.23 0.23 0.32 0.32 0.48 0.48 0.48 0.64
Ventilation (ERV plus)
(AM****NKDEH/**)
0.11 0.36
Hydro Unit HE
(AM****NBDEH/**)
0.60 0.70 1.20
Hydro Unit HT
(AM****NBF*B/**)
0.60
Note1)
MCU (MCU-S*NE**N)
0.50
※ If there is no additional refrigerant value for the indoor unit in the above table, refer to the indoor unit installation manual.
