27
English
Installation Procedure
Refrigerant pipe installation
• Basic amount of refrigerant within the outdoor unit (kg)
– Amount of additional refrigerant has to be calculated based on the sum of all liquid pipe length.
H/P
Classification AM080AXVANH* AM100AXVANH* AM120AXVANH* AM140AXVANH* AM160AXVANH*
Basic amount (kg) 5.5 5.5 6.2 7.0 8.0
Classification AM180AXVANH* AM200AXVANH* AM220AXVANH* AM240AXVANH* AM260AXVANH*
Basic amount (kg) 8.0 10.5 10.5 14.0 14.0
Classification AM280AXVANH* AM300AXVANH* AM320AXVANH* AM340AXVANH*
Basic amount (kg) 14.0 15.5 15.5 15.5
Classification AM080AXVGNH* AM100AXVGNH* AM120AXVGNH* AM140AXVGNH* AM160AXVGNH*
Basic amount(kg) 7.0 7.0 7.0 8.5 8.5
Classification AM180AXVGNH* AM200AXVGNH* AM220AXVGNH* AM240AXVGNH* AM260AXVGNH*
Basic amount(kg) 10.5 10.5 10.5 14.0 14.0
C/O
Classification AM080AXVANC* AM100AXVANC* AM120AXVANC* AM140AXVANC* AM160AXVANC*
Basic amount (kg) 5.5 5.5 6.2 7.0 8.0
Classification AM180AXVANC* AM200AXVANC* AM220AXVANC* AM240AXVANC* AM260AXVANC*
Basic amount (kg) 8.0 10.5 10.5 11.0 11.0
Classification AM280AXVANC* AM300AXVANC* AM320AXVANC* AM340AXVANC*
Basic amount (kg) 11.0 11.0 12.5 12.5
H/R
Classification AM080AXVANR* AM100AXVANR* AM120AXVANR* AM140AXVANR* AM160AXVANR*
Basic amount(kg) 7.0 7.0 7.0 8.5 8.5
Classification AM180AXVANR* AM200AXVANR* AM220AXVANR* AM240AXVANR* AM260AXVANR*
Basic amount(kg) 10.5 10.5 10.5 14.0 14.0
Classification AM280AXVANR*
Basic amount(kg) 14.0
• Amount of additional refrigerant depending on the pipe size ( )
– Amount of additional refrigerant has to be calculated based on the sum of all liquid pipe length.
Size of liquid pipe Ø 6.35 Ø 9.52 Ø 12.70 Ø 15.88 Ø 19.05 Ø 22.22 Ø 25.40 Ø 28.58
Additional amount
(kg/m)
0.02 0.06 0.125 0.18 0.27 0.35 0.53 0.65
Amount of
refrigerant added
when the diameter
of liquid pipe is
reduced (kg/m)
- 0.08 0.13 0.195 0.28 0.42 0.53 -
– For the indoor unit already connected to EEV kit, the additional refrigerant charging is 0.01kg per meter regardless of the pipe size.
