Wiring work
38
English
Installation manual
Selecting the crimping terminal lug
1 Select the crimping terminal lug based on the norminal dimension of the power cable.
2 Cover the connection part of the power cable and crimping terminal lug to insulate it.
d2
B
d1
D
F
Silver solder
t
L
E
Norminal
dimensions
for cable
(mm²)
Norminal
dimensions
for screw
(mm)
B D d1 E F L d2 t
Standard
dimension
(mm)
Allowance
(mm)
Standard
dimension
(mm)
Allowance
(mm)
Standard
dimension
(mm)
Allowance
(mm)
Min. Min. Max.
Standard
dimension
(mm)
Allowance
(mm)
Min.
1.5
4 6.6
± 0.2 3.4
+0.3
-0.2
1.7 ± 0.2 4.1 6 16 4.3
+0.2
0
0.7
4 8
2.5
4 6.6
± 0.2 4.2
+0.3
-0.2
2.3 ± 0.2 6 6 17. 5 4.3
+0.2
0
0.8
4 8.5
4 4 9.5 ± 0.2 5.6
+0.3
-0.2
3.4 ± 0.2 6 5 20 4.3
+0.2
0
0.9
