ENGLISH-11
Moving the Outdoor Unit
▶ Select the moving route in advance.
▶ Be sure that moving route is safe from the weight of the outdoor unit.
▶ Do not slant the product more than 30˚ when carrying it. (Do not lay the product down sideways.)
▶ The surface of the heat exchanger is sharp. Be careful not to get injured while moving and installing.
When moving with a crane or wire rope
▶ When moving an outdoor unit to a higher place such as the rooftop.
- Fasten the wire rope as seen in the picture.
- Move the outdoor unit with the product packed to prevent possible
product damage during the transportation.
Wire rope /
straps
Wood palette
When moving an outdoor unit with hands
▶ Moving the outdoor unit by lifting up and carrying due to the short travel distance.
- Two people should carry the outdoor unit by holding transportation handle.
- Be careful not to damage the heat exchanger of the rear side of the outdoor unit
during transportation.
- Be careful not to get hurt by the sharp surface of the heat exchanger.
Selecting installation location
Decide the installation location based on the following condition and obtain the user’s approval.
▶ Avoid a place that may disturb your neighbor. Noise may occur from the outdoor unit and the discharged
air may run into the neighborhood. (Be careful of the operation time in a residential area)
▶ Install the outdoor unit on a hard and even area that can support its weight.
▶ Choose a at place where rainwater does not settle or leak.
▶ Choose a place that will avoid strong winds.
▶ Choose a place that is well ventilated and allows enough space for repairs and service. (Discharge duct can
be purchased privately.)
▶ Choose a place where the connection of refrigerant pipe between an indoor unit and outdoor unit is within
allowed distance.
▶ Make sure that the condensed water dripping from the drain hose runs out properly and safely.
▶ Choose a place where ammable gas does not leak.
▶ Choose a place where the unit could not come into contact with snow and rain.
▶ When installing the outdoor unit near sea shore, make sure it is not directly exposed to sea breeze.
- When installing the outdoor unit near sea shore, consult the qualied installer since the places above
require additional measures for corrosion resistance. (You should remove salt and dust of a heat
exchanger at least once a year.)
