ENGLISH-33
02 INSTALLATION
Selecting the insulator of the refrigerant pipe
f According to pipes size, insulate pipes on gas and liquid side by selecting appropriate insulations.
f Standard condition is under a temperature of 30°C and a humidity of 85%. If the units are installed in extreme weather
conditions, select the insulator by table below.
Pipe type Pipe diameter (mm)
Thickness of insulator
Remarks
Normal
(Under 30°C, 85%)
High humidity
(Over 30°C, 85%)
EPDM, NBR
Liquid
ø6.35~ø19.05 9 9
The material shall has
heat resistant over
120°C
ø12.70~ø19.05 13 13
Gas
ø6.35 13 19
ø9.52
19 25
ø12.70
ø15.88
ø19.05
• Install the insulation not to be get wider and use the adhesives on the connection part of it to prevent moisture
entering.
• Wind the refrigerant pipe with insulation tape if it is exposed to outside sunlight.
• Install the refrigerant pipe respecting that the insulation does not get thinner on the bent part or hanger of pipe.
CAUTION
Insulating the refrigerant pipe
f You must check if there is a gas leak before completing all the installation process.
f Use EPDM insulation which meets the following condition.
Item Unit Standard Remarks
Density g/cm² 0.048~0.096
KSM 3014-01Dimension change route by heat % -5 or less
Water absorption rate g/cm² 0.005 or less
Thermal conductivity kcal/m·h·˚C 0.032 or less KSL 9016-95
Moisture transpiration factor ng/(m²·s·Pa) 15 or less KSM 3808-03
Moisture transpiration grade {g/(m²·24h)} 15 or less KSA 1013-01
Formaldehyde dispersion mg/L - KSF 3200-02
Oxygen rate % 25 or less ISO 4589-2-96
