Adjusting air ow
With its phase control motor, you can adjust the indoor unit fan speed depending on the installation condition.
If the external static pressure is high so that the duct becomes longer or if the external static pressure is low so
that the duct becomes shorter, adjust the fan speed by referring the following table.
E. S. P(External Static Pressure) setting for phase control motor
Model AC052NNMSEC AC071NNMSEC
Static Pressure (mmAq) Option code for indoor unit
SP=3
01B152-1D0561-234700-340102 01B152-1D0928-247700-340102
3<SP≤6
01B152-1D05E8-234700-340102 01B152-1D098D-247700-340102
6<SP≤9
01B152-1D0A60-234700-340102 01B152-1D0AF2-247700-340102
9<SP≤12
01B152-1D0AD4-234700-340102 01B152-1D0E46-247700-340102
12<SP≤15
01B152-1D0E39-234700-340102 01B152-1D0E9B-247700-340102
Model AC090NNMSEC AC100NNMSEC
Static Pressure (mmAq) Option code for indoor unit
SP=4
01B152-1D0921-25A700-340122 01B152-1D0921-264710-340122
4<SP≤8
01B152-1D09C7-25A700-340122 01B152-1D09C7-264710-340122
8<SP≤12
01B152-1D0D2C-25A700-340122 01B152-1D0D2C-264710-340122
12<SP≤15
01B152-1D0E60-25A700-340122 01B152-1D0E60-264710-340122
Model AC120NNMSEC AC140NNMSEC AC160NNMSEC
Static Pressure (mmAq) Option code for indoor unit
SP=5.2
01B152-1D047C-
278710-340142
01B152-1D047C-
28C710-340142
01B152-1C0924-
2A0710-340142
5.2<SP≤8
01B152-1D04CD-
278710-340142
01B152-1D04CD-
28C710-340142
01B152-1C0978-
2A0710-340142
8<SP≤12
01B152-1D0912-
278710-340142
01B152-1D0912-
28C710-340142
01B152-1C09CC-
2A0710-340142
12<SP≤15
01B152-1D0974-
278710-340142
01B152-1D0974-
28C710-340142
01B152-1C09FF-
2A0710-340142
NOTE
• represents E. S. P(External Static Pressure) range of factory setting.
You don’t have to adjust the fan speed separately if the external static pressure of the installation place is in
. When it is out of
, input the appropriate option code.
•
If you input the inappropriate option code, error may occur or the air conditioner is out of order. The
option code must be inputted correctly by the installation specialist or service agent.
