English
Setting an indoor unit address (MAIN/RMC)
1. Check whether power is supplied or not.
f When the indoor unit is not plugged in, there should be additional power supply in the indoor unit.
2. The panel(display ) should be connected to an indoor unit to receive option.
3. Before installing the indoor unit, assign an address to the indoor unit according to the air conditioning system plan.
4. Assign an indoor unit address by wireless remote controller.
f The initial indoor unit ADDRESS is set as “MAIN : 0, RMC : 0”.
f Set Main and RMC Address only the setting is required.
f There is no need to assign the indoor unit Main Address if the outdoor unit is addressing automatically.
The indoor unit Main address will follow the outdoor unit’s automatically.
f Assign 12 digit when setting the indoor unit address.
f No need to assign SEG4, 5, 8, 10 which are non applicable. Even though those segments are set, they will be
ignored.
f If you set the applicable segments with numbers other than the indiciated, the initial setting will be maintained.
Option No. : 0AXXXX-1XXXXX-2XXXXX-3XXXXX
Option SEG1 SEG2 SEG3 SEG4 SEG5 SEG6
Explanation PAGE MODE Setting Main address
RESERVED RESERVED
The unit digit of an
indoor unit
Indication
and Details
Indication Details Indication Details Indication Details Indication Details
0 A
0
No Main
address
0~3
A single
digit
1
Main address
setting mode
Option SEG7 SEG8 SEG9 SEG10 SEG11 SEG12
Explanation PAGE
RESERVED
Setting RMC address
RESERVED
Group channel(*16) Group address
Indication
and Details
Indication Details Indication Details Indication Details Indication Details
1
0
No RMC
address
RMC1 0~2 RMC2 0~F
1
RMC address
setting mode
• You can set the Main address(SEG6) 0~3 range and if you set other numbers,”communication
error”will occur.
• If you set the SEG 3 as 0, the indoor unit will maintain the previous MAIN ADDRESS even if you
input the option value of SEG6.
• If you set the SEG 9 as 0, the indoor unit will maintain previous RMC ADDRESS even if you input
the option value of SEG11~12.
CAUTION
Example) If you want to set as “MAIN : 3, CHANNEL : 1, RMC : B”,
SEG1 SEG2 SEG3 SEG4 SEG5 SEG6
0 A 1 - - 3
SEG7 SEG8 SEG9 SEG10 SEG11 SEG12
1 - 1 - 1 B
Setting an indoor unit address and installation option
