AA
18
English
The following accessories are supplied with the indoor unit.
The type and quantity may differ depending on the specications.
Accessories
Pattern sheet Insulation cover
pipe A
Insulation cover
pipe B
Insulation drain Flexible hose clamp
Flexible hose Cable-tie user & installation
manual
Preparation for installation
Indoor unit
Space requirements for indoor unit
There must be no obstacles near the air inlet and outlet.
Install the indoor unit on a ceiling that can support its weight.
Maintain sufcient clearance around the indoor unit.
Make sure that the water dripping from the drain hose runs away correctly and safely.
The indoor unit must be installed in this way, that they are out of public access. (Not touchable by the users)
1500mm or more
1500mm or more
1500mm or more
1500mm or more
CAUTION
• If you install the cassette or duct type indoor unit on the ceiling with temperature over
27°C or humidity over 80%,you must apply extra 10mm of polyethylene foam or other
insulation with similar material on the body of the indoor unit.
Deciding on where to install the indoor unit
