Installation Procedure
3- phase
Model Outdoor unit Input current (A) Power supply
Indoor unit Outdoor unit Hz
Voltage range (V) Outdoor unit
Indoor unit Total MCA(A) MFA(A)
Rated Min. Max. Cooling Heating
AC100BN4DEH
AC100BXADGH
50 380 to 415 342 456.5 12.0 12.0 2.0 14.0 14.0 15.4
AC100BNCDEH 50 380 to 415 342 456.5 12.0 12.0 2.0 14.0 14.0 15.4
AC100BNMDEH 50 380 to 415 342 456.5 12.0 12.0 2.5 14.5 14.5 16.0
AC100BN6DEH 50 380 to 415 342 456.5 12.0 12.0 2.5 14.5 14.5 16.0
AC120BN4DEH
AC120BXADGH
50 380 to 415 342 456.5 12.0 12.0 1.2 13.2 13.2 15.0
AC120BN6DEH 50 380 to 415 342 456.5 12.0 12.0 1.4 13.4 13.4 15.0
AC120BNMDEH 50 380 to 415 342 456.5 12.0 12.0 1.9 13.9 13.9 15.2
AC120BNCDEH 50 380 to 415 342 456.5 12.0 12.0 1.6 13.6 13.6 15.0
AC180BNHDEH AC180BXADGH 50 380 to 415 342 456.5 12.0 12.0 2.5 14.5 14.5 16.0
NOTE
1 Voltage range
• Units are suitable for use on electrical systems where voltage supplied to unit terminal is not below or above listed
range limits.
2 Maximum allowable voltage variation between phases is 2%.
3 Wire size & type must comply with the applicable local and national code.
• Wire size: Based on the value of MCA.
• Wire type: 60245 IEC57(IEC) or H05RN-F(CENELEC) grade or more.
4 MFA is used to select the circuit breaker and the ground fault circuit interrupter (earth leakage circuit breaker).
5 MCA represents maximum input current.
• MFA represents capacity which may accept MCA
• Abbreviations
MCA: Min. Circuit Amps. (A)
MFA: Max. Fuse Amps. (A)
6 This equipment complies with IEC 61000-3-12 provided that the short-circuit power Ssc is greater than or equal to Ssc (*2)
at the interface point between the user’s supply and the public system.It is the responsibility of the installer or user of the
equipment to ensure, by consultation with the distribution network operator if necessary, that the equipment is connected
only to a supply with a shortcircuit power Ssc greater than or equal to Ssc(*2).
Model Ssc[MVA]
AC100BXADEH 1.4
AC120BXADEH 1.9
